CHISUM CHALLENGER XLT

THE CHALLENGER XLT FRAME OFFERS:

  • Length 20′ 0″ treadways
  • 25′ 6’/;’ with loading ramps
  • 24′ 2″ with towers positioned front and rear
  • Width 7′ 4″ total bed width
  • 11′ 6″ with towers on either side
  • 26’/,’ treadway width
  • 35’/;’ width between treadways
  • Working Height 12″ with lift fully lowered
  • 411/2″ with lift fully raised
  • Machine Height 9′ 1’/;’ with lift fully raised and tower heads   fully lowered
  • 9′ 11’/2″ with lift fully raised and tower heads fully extended
  • Weight (in Ibs.) 8,470 with three towers
  • Hydraulic Power 10 tons per tower
  • Lift Capacity 10,000 Ibs.
  • Tie Downs 230
  • Grease Fittings 3 per tower

THE FINEST

The Chisum Challenger is the world’s #1 drive-on frame machine with a precision-milled deck. After fabrication, each Challenger mainframe spends 48 hours running through a computer-controlled milling machine. This process eliminates any distortion in the steel and ensures that the entire mainframe is 100% true, both end-toned and side-to-side, including all crossmember.

The Chisum Challenger is guaranteed to be accurate and delivers the flattest surface in the industry from which to measure. Plus, it has a phenomenal finished appearance that captivates all who see it. No need to pinch yourself! Simply adjust this perfect pulling surface to a comfortable working height, and you’re ready to produce more accurate repairs than ever before.

Chisum Challenger: Finished Like No Other

SEE THE DIFFERENCE

Chisum Challenger: See the Difference

STRENGTH LIKE NO OTHER

Chisum Challenger: Strength Like No Other

THE NEW CHISUM CHALLENGER

Chisum Challenger: The New Chisum Challenger
Chisum Challenger: Quality You Can See

LEGENDARY LAVELL CHISUM TELESCOPING TOWER HEADS

FAMOUS TEN-TON TOWERS

ADJUSTABLE COLLARS FOR EASY POSITIONING

CONVENIENT STORAGE LOCATION FOR EACH TOWER PIN

TRUE 360 DEGREE PULLING POWER

The Chisum Story
THE CHISUM DIFFERENCE
Chisum frame straightening machine and collision repair equipment’s stringent manufacturing specifications guarantee your ™Challenger XLT frame machine is the finest in the world. As evidence of the Challenger XLT’s superior quality and workmanship, simply examine its perfectly smooth, precision-milled tread ways. Or watch one of its towers glide with ease along the entire length of the machine. The difference is visible. That’s why the Chisum Challenger XLT frame straightening machine leads the industry.



IT’S BUILT TO LAST
Plus, it’s got more power. In fact, with a ™Challenger XLT in your shop, you command 30 tons of total pulling power. Each of the machine’s legendary ™Chisum towers is powered by SPX hydraulics and can be positioned next to any other tower for combined pulling strength.

Finally, consider the Challenger XLT’s convenience. With just the touch of a button you position the vehicle at your preferred working height for each step in the repair process anywhere from 12″ to over 41″ off your shop floor.

Unbeatable quality, comfort, and efficiency!
